Moderne LED Wechselverkehrszeichen in RGB
The Traco Sign is the essential component of our portfolio, ensuring optimal image quality in all weather conditions with its freely programmable LED variable message signs in RGB colors. With our SafeTracx software application, you have full control over each of the 5,120 pixels—conveniently from your PC.
 |
Multi-colour - 256 RGB colours The RGB colours are mixed by a modern optical system so that full-colour displays with an ideal light image are guaranteed at all times. The light from the LEDs is focussed and projected exactly where it is needed. |
 |
Dynamic brightness control Brightness sensors constantly detect the ambient brightness. The brightness of the LEDs is constantly adjusted to the ambient light to ensure an optimum signalling image and good visibility for road users at all times. |
 |
Pixel pitch 20 mm (M-TI compliant) The individual LEDs or pixels are arranged in a grid dimension of 20 mm as standard. This corresponds to the specifications for temporary use from the information sheet for boards with photometric information (M-TI). Other pixel pitches are available on request. |
 |
Standard size 64 x 80 pixels LED variable message signs with a width of 64 pixels and a height of 80 pixels are available as a standard size. This results in a display area of 1,280 mm wide and 1,600 mm high. Other sizes are available on request. |
|
Optical Properties |
|
|
Luminance |
L3 (*) |
|
Luminance Ratio |
R3 |
|
Beam Angle |
B6 |
|
(B7 possible upon request) |
|
|
Color |
C2 |
|
Durability |
T2 |
|
D3 |
|
|
Load & Protection Rating |
|
|
Horizontal Load |
PAF1, WL9, DSL0, TDB2, TDT2 |
|
IP Protection Rating |
IP56 |
